DL280-1 display screen smoke absorber
1.Purification of smoke and dust generated by soldering station operation,laser engraving,marking, etc.
2.Imported high-pressure,low-noise fans, which can effectively absorb soot particles and maximize the service life of the filter elements
3.The control system adots PWM speed reulation, the control system is designed with an indicator light alarm device when the filter element is blocked,the red indicator light will light up,prompting to replace the filter element;
4. The filtration system is composed of three parts: a pre-filter layer, a main filter layer and a gas filter layer. The pre-filter layer can absorb relatively large particles in the air flow to prevent the main filter layer from being blocked prematurely; the main filter layer is made of HEPA high-effi ciency filter elements Composition.the HEPA high efficiency filter element has a filtration efficiency of 9999% for 03 micron particles. The gas filter layer is composed of a chemical filter element which can effectively remove harmful gases in the airflow
Input voltage: AC220V/110V
Power:200W
Filters:3 layers
Wind speed: 1x 13m/s
Filtering effect: 0.3μm99.5%
Noise: <65dB
Smoke absorption pipe: 1*Φ75mm*L 1.4M
Air volume: 350m³/h
Size: W425*L235*H480mm
Weight: 17.56KG
